iTel IP66 12kW / 17kW On-Grid Solar Inverter – IHY-KTLC Series
iTel IP66 12kW / 17kW On-Grid Solar Inverter – IHY-KTLC Series

itel Pakistan

iTel IP66 12kW / 17kW On-Grid Solar Inverter – IHY-KTLC Series

Rs.0
What power options are available in the itel IP66 On-Grid Solar Inverter IHY-KTLC Series?

The IHY-KTLC Series is available in 12kW and 17kW models, making it suitable for medium to large residential, commercial, and industrial three-phase solar systems.

Is the itel IHY-KTLC Series suitable for outdoor installation?

Yes. The inverter features an IP66-rated enclosure, providing excellent protection against dust, rain, and harsh weather conditions for reliable outdoor operation.

How efficient is the itel IP66 12kW/17kW On-Grid Solar Inverter?

The inverter delivers up to 98.7% maximum conversion efficiency and 99.9% MPPT tracking efficiency, helping maximize solar energy production.

Does the itel IHY-KTLC Series support multiple MPPT trackers?

Yes. It comes with 2 independent MPPT trackers, allowing better energy harvesting from multiple solar panel strings installed at different angles.

What communication options are available with the itel IHY-KTLC Series inverter?

The inverter supports Wi-Fi, RS485, and GPRS communication, enabling remote monitoring and easy system management through compatible monitoring platforms.

In stock, ready to ship

Buy with QistBazaar (Pay in Installments)

Qist Bazaar

Pairs well with

Official Warranty

Quick Delivery

2 Million+ Satisfied Customers

Secure Checkout

Product Parameters

Why it Stands Out?

The iTel 12kW IP66 3-Phase is the most powerful inverter in the iTel hybrid lineup, designed for commercial buildings, large compounds, and industrial applications on a three-phase supply. It delivers 12,000W of continuous three-phase output across 220/380V or 230/400VAC, with a 24,000W surge capacity and a 10ms switchover time that ensures zero-interruption backup power. IP66 protection enables a fully outdoor installation without any enclosure. The dual MPPT system accepts up to 24,000W of PV input with a maximum discharge current of 250A. Operating reliably from -25°C to 60°C and up to 4,000m altitude, it is built for demanding conditions. Full communication support via WiFi, RS485, CAN, and Dry Contact enables seamless integration into any building management or monitoring system.

Description Reviews Specifications
Feature Details
Model IHY-12KTLC / IHY-17KTLC
Rated Output Power 12kW / 17kW
Inverter Type 3-Phase On-Grid Solar Inverter
Protection Rating IP66 Dust & Water Resistant
Maximum PV Input Voltage 1100V DC
MPPT Dual MPPT Trackers (2)
Maximum Efficiency Up to 98.7%
Communication Wi-Fi, RS485 & GPRS
Cooling Method Smart Air Cooling
Application Residential, Commercial & Industrial Solar Systems
